<- 79017 | 79018 | 79019 ->

Vehicle 79018 / 975007


Derby Lightweight

Builder: BR Derby Works
Layout: Low Density
Length: 57ft
Coupling Code: Yellow Diamond
Coupling Type: Screw
Gangway Type: LMS
Engines: AEC 150hp
Transmission: Mechanical
Lot Number: 30123
Diagram: 503

Allocations

22/01/55 New to 12A (Carlisle Upperby)
4w/e 16/07/55 Transferred to 12D (Workington)
Oct-55Depot code change12C
Apr-58Depot code change11B
Jun-60Depot code change12F
Sep-63Depot code change12D
3w/e 28/02/65 Transferred to 12B (Carlisle Upperby)
4w/e 08/06/68 Withdrawn from 12B (Carlisle Upperby)
01/11/70 To departmental stock
by Dec-75 Transferred to OC (Old Oak Common)
by 03/03/80 Transferred to RG (Reading)
by 01/01/85 Transferred to OC (Old Oak Common)
by 04/01/86 Transferred to RG (Reading)
1994 Withdrawn

Notes

11/08/81 - On the night of 10/11 August 1981 TDB 975007/975008 operated from Reading to Eastleigh via Salisbury and Southampton. The following day they operated from Eastleigh to Stewarts Lane via Basingstoke, Woking, Guildford and Redhill.
25/10/82 - The Ultrasonic test train could be found working on the SR on three consecutive nights between 25 and 28 October 1982. 975007 and 975008 worked between Reading and Waterloo; over South Eastern Division suburban routes from Victoria and Holborn Viaduct; and on the Central Division between Clapham Junction, Three Bridges and Horsham via the Quarry line, also Horsham - Leatherhead.
26/06/83 - DB975007/008 were back on the Southern Region on 26/6/83. That night they ran over South Western Division territory, the next over South Eastern, and Central division on 28/29th. They returned to the South Western on 30 June, finishing at Reading Triangle Sidings at 05:02 on the morning of 1 July.
Aug-83 - In the last week of August 1983 975007/8 were working on lines in the West of England.

The vehicle carried the following numbers:

79018 - original number
975007 - from Oct-70 (departmental stock)

Department Use as DB975007

Ultrasonic Test Train From 11/70 to 1994.

Disposal

Preserved - moved Doncaster Works to Midland Railway Butterley March 1997 - more details.

Some sample formations the vehicle has been noted in:


79018 79610 As delivered to 12A - 22nd January 1955
79018 79641 Noted 19/12/67 - at Carnforth with 79121 + 796031
975007 975008 Noted 05/04/71 - at Old Oak Common1
975007 975008 Noted 25/02/73 - at Tyseley1
975007 975008 Noted 30/04/75 - on Old Oak Common depot2
975007 975008 Noted 17/05/82 - at Norwich2
975007 975008 Noted 30/01/84 - at Norwich2
975007 975008 Noted 12/12/1985 - at Shenfield3

Formation Sources
1: Leonard Rogers
2: Gerald Brown
3: Robert Chilton

Images:

Inside a Derby lightweight

circa March 1971

The two generators in the former brake van of 975007, the power car on the Derby Lightweight Ultrasonic Test Train. The inner rail around the top is part of the fire suppression system similar to that fitted above DMU engines. Image courtesy of Philip C Johnson. British Railways Board.

Inside a Derby lightweight

circa March 1971

An official image showing the crew kitchen / mess area on DB975007, part of the ultrasonic test train, circa March 1971. British Railways Board.

Derby lightweight at an unknown location

circa March 1971

An official image showing British Railways new two-vehicle ultrasonic rail testing train at work. The power car DB975007 is leading, the trolley carrying the ultrasonic probes is mounted underneath the trailer car (DB975008). Taken circa March 1971, the vehicles were formerly M79018 and M79612 based in the West Cumberland area. British Railways Board.

Derby lightweight at Tyseley

circa 1971

Reading based Derby Lightweight "Low Density" 2-car DMU DB975007 (formerly DMBS M79018) and DB975008 (DTC M79612) operating as Ultrasonic Test Train at Tyseley - c.1971. Both cars are now preserved at the Ecclesbourne Valley Railway. 53A Models of Hull Collection.

Derby lightweight at Old Oak Common depot

circa early 1970s

The Ultrasonic Test Train 975007 + 975008 in Old Oak Common Depot circa early 1970s. Tony Wilkins.

Derby lightweight at Stratford depot

11th July 1973

The Derby Lightweight Ultrasonic Test Train DB975007 + DB975008 in Stratford Depot on 11 July 1973. Alistair Ness.

Derby lightweight at Stewarts Lane depot

22nd October 1973

DB975007 stabled on Stewarts Lane depot on 22 October 1973. Alistair Ness.

Derby lightweight at Preston

September 1975

DB9750017 from the Ultrasonic Test Train seen at Preston Power Box during September 1975. Ian 10B.

Derby lightweight at Leamington Spa

30th March 1979

The Derby Lightweight Ultrasonic Test Train 975007 + 975008 seen at Leamington Spa on 30/03/1979. Graeme Phillips Collection.

Derby lightweight at Faversham

Unknown date

975007 + 975008, the Ultrasonic Test Train at Faversham. Date unknown. Stuart Pearce.

Derby lightweight at Sonning

4th March 1980

The Derby Lightweight Ultrasonic Test Train 975007 + 975008 seen at Sonning on 4 March 1980. Brian Daniels.

Derby lightweight at Reading depot

14th April 1980

The Derby Lightweight Ultrasonic Test Train 975007 + 975008 stabled on Reading Depot on 14 April 1980. Brian Daniels.

Derby lightweight at East Croydon

24th February 1981

This ultrasonic test train comprised a train of Derby lightweight dmu coaches M79018 (renumbered DB975007) and M79612 (DB975008). This view was taken from the SR Central Divisional HQ (Essex House) on 24 February 1981. Jeremy Chapter.

Derby lightweight at Berwick-upon-Tweed

2nd July 1981

The Ultrasonic test train 975007 and 975008 stands at Berwick-upon-Tweed on 3rd July 1981. Paul Bettany.

Derby lightweight at Reading

25th September 1982

The Ultrasonic Test Train 975007 / 975008 seen at Reading on the 25th September 1982. Jerry Glover.

Derby lightweight at York

May 1983

DB975007 of the Ultrasonic Test Train seen on York station in May 1983. George Woods.

Derby lightweight at Eastfield depot

circa April 1984

The Ultrasonic Test Train (975007 + 975008) at Eastfield TMD circa April 1984. Spannerman37025.

Derby lightweight at Craigendoran Junction

April 1984

The Ultrasonic Test Train (975007 + 975008) at Craigendoran Junction in April 1984. Spannerman37025.

Derby lightweight at Garelochhead

15th April 1984

6Z08 Ultrasonic Test Train (975007 / 975008) near Garelochhead on 15/4/84. Driver Peter Walker and secondman Brian Guthrie look fed up sat in the back cab. Spannerman37025.

Derby lightweight at Wigan North Western

6th July 1985

Displaying the headcode 6Z08, Ultrasonic Test Train DB975007 - DB975008 arrives at the south end of platform 6 at Wigan North Western, 6th July 1985. Built in 1955 the unit had been converted to departmental use 15 years earlier and would eventually be secured for preservation after final withdrawal in 1994. S Gaskell.

Derby lightweight at Leamington Spa

10th August 1985

This is what the Ultrasonic Test Train looked like in 1985. It consisted of two Derby Lightweight DMU vehicles carrying the numbers 975007 + 975008 and on 10 August of that year was carrying the reporting number 6Z08 while running from Derby to Marylebone when I photographed it passing Leamington Spa station. Peter Tandy.

Derby lightweight at Newcastle

22nd October 1985

The Derby Lightweight Ultrasonic Test Train 975007 + 975008 at Newcastle on 22/10/1985. Graeme Phillips Collection.

Derby lightweight at Tyseley

23rd August 1986

975007 is seen at Tyseley carriage sidings on 23.08.1986 coupled to it's long time partner 975008. Andy Cole.

Derby lightweight at Reading

July 1987

The Derby Lightweight Ultrasonic Test Train 975007 + 975008 rests probably at Reading station, circa July 1987. Stuart Mackay Collection.

Derby lightweight at Tyseley

16th January 1988

975007 is seen stabled at Tyseley on 16.01.1988. It was converted from 79018, and was used as an ultrsonic test train. Andy Cole.

Derby lightweight at Reading

25th July 1988

975007/975008 seen at Reading on 25/7/88. Hamish Stevenson.

Derby lightweight at Leicester

Unknown date

The Ultrasonic Test Train 975007 / 975008 in the sidings next to Leicester Station - date unknown. Ian Francis.

Derby lightweight at Old Oak Common

Unknown date

Unknown location and date, probably Old Oak Common after withdrawal. Nick Green.


The vehicle is mentioned in the following images:

DMU

Date: circa 1970

The cab of one of the vehicles (975007 or 975008) on the Derby Lightweight Ultrasonic Test Train showing the loggers seat and panel. If you look carefully you should see a fine vertical rod attached to and set in from the outer edge of the drivers window. There was one on each side for the logger to line up this with the mile posts as they were passed. This was recorded on the film to give the film examiner a method to precisely locate the location of any defects detected. The driver had a similar set up in front of him to activate a trolley axle locking system when passing through crossovers or S&C. This was necessary as the axles of the trolley were spring loaded outwards to ensure the flanges were always pressed against the gauge corner. Philip C Johnson.

DMU

Date: circa March 1971

An official image showing the cab of one of the vehicles (975007 or 975008) of the ultrasonic test train circa March 1971. The extra raised seat in the centre of the cab was for the logger who would use the keyboard on the console to note the sighting of lineside mileposts which would record then on the film produced by the ultrasonic test gear. A third seat, out of view, was fro the train captain. Note the traditional Yellow Diamond 'cowhorn' throttle and the matching early style gear controlled has been replaced by the later style controls used on Blue Square vehicles. British Railways Board.

DMU

Date: circa March 1971

An official image showing the cab of one of the vehicles (975007 or 975008) of the ultrasonic test train circa March 1971. The crew are sitting in position, probably just posing for the photograph, the driver to the left and the logger on the right. Out of sight to the right is another seat position for the train captain. British Railways Board.

DMU

Date: Spring 1971

All of the original West Cumberland trailer cars (M79600-12) were scrapped by Arnott Young at various locations other than two which moved to Derby. There one became part of the Ultrasonic test train, the other, M79610 (which was the original partner of the ultrasonic test train power car M79018) was scrapped at Cohens in Kettering in early 1971, where it is pictured. Tony Wilkins.

DMU

Date: 11th December 1976

The Ultrasonic Test Train, DB975008 - 975007 (formerly Derby Lightweight M79612-M79018) at Old Oak Common depot on 11 December 1976. The DMU found its way into preservation as a result of its extended career in departmental service. Photographer - Roy Burt. Gordon Edgar Collection.

DMU

Date: unknown

The Ultrasonic Test Train (975008 + 975007) at Stratford depot, date unknown. Peter also sent an accompanying image of a new German UTT at Stratford, and noted "when tested against each other the new German one missed so many faults on the stretch of line it was sent back"! Peter Boor.

DMU

Date: unknown

The Ultrasonic Test Train - 975008 + 975007 - location / date unknown. Walter Burt.

DMU

Date: 24th February 1981

In the long-disappeared siding at East Croydon sits the Ultrasonic Test Train 975008/975007 on February 24, 1981. Jeremy Chapter.

DMU

Date: circa early/mid-1980s

Derby LIghtweight Ultrasonic Test Train 975008 + 975007 on Reading depot circa early/mid-1980s. Mike Bunker.

DMU

Date: 1983

The Derby Lightweight ultrasonic test train 975008 / 975007 seen at Stewarts Lane in 1983. John Law.

DMU

Date: 12th March 1983

Former Derby Lightweight DMU 975008 + 975007 and ex-Class 501 EMUs now battery electrics (probably 97-703 and 97-704) inside Cricklewood running shed on 12-3-83. On Tour With the Class 13 Army.

DMU

Date: May 1983

The Ultrasonic Test Train, 975008 + 975007, in York station in May 1983. George Woods.

DMU

Date: 7th May 1983

With a red flag 'planted' between the rails as protection, the Derby Lightweight RTC Ultrasonic Test Train formed of cars DB975008 & DB975007 was stabled in the sidings at Dock Street, Preston on May 7th 1983. The unique vintage DMU was replaced by a heavily modified Metro-Cammell DMU (901001) in 1986, and subsequently the last surviving original Derby Lightweight two-car set fortunately passed into preservation. Martyn Hilbert.

DMU

Date: circa April 1984

The Ultrasonic Test Train (975008 + 975007) at Faslane on West Highland Line. Circa April 1984. Spannerman37025.

DMU

Date: circa 1985

From the kitchen window of my then nearby home on a date I can't find in my notebooks, but probably in 1985, I saw 31426 arrive at Stratford-upon-Avon with the Derby Lightweight Ultrasonic Test Train (TDB975007/8) in tow. It went into the Down Goods Loop where the class 31 was detached, ran along the up main line to the crossover before being coupled to 6Z08 and prepared to leave. Here, the second man watches the locomotive approach along the by then rarely used loop which was taken out of use within a few weeks. Peter Tandy.

DMU

Date: circa 1985

From the kitchen window of my then nearby home on a date I can't find in my notebooks, but probably in 1985, I saw 31 426 arrive at Stratford-upon-Avon with the Derby Lightweight Ultrasonic Test Train (TDB975007/975008) in tow. It went into the Down Goods Loop where the class 31 was detached, ran along the up main line to the crossover before being coupled to 6Z08 and prepared to leave. After a brake test carried out I took this picture as 6Z08 left the loop to use the crossover (which the signalman maintained wasn't fit to use!) and joined the up main line towards Bearley Junction. Peter Tandy.

DMU

Date: 1st August 1985

The Derby Lightweight Ultrasonic Test train 975008 + 975007 stopped at Leamington Spa. The driver is on the phone to the Signal box visible beyond him, officially Leamington Spa SB though the cast nameboard included North, but not picked out in white, while the diagram included Jc. The adjacent box to the South was by then, Fenny Compton. The new SSI PSB is behind the photographer then in shadow mode. P42 is a power operated derailer as there isn't room for a trap point. Nicholas T Smith.

DMU

Date: unknown

Reading stabling point taken from a Reading to Baskingstoke train. The Derby Lightweight Ultrasonic Test Train (975007 (closest)/975008) can be seen, as well as 117s, a 101 centre car and a 119 DMBC with a bashed cab. John McIntyre.

DMU

Date: 23rd August 1986

975008 is seen stabled at Tyseley on 23.08.1986. It was converted from 79612, and is with partner 975007. Andy Cole.

DMU

Date: July 1987

The Ultrasonic Test Train 975008 + 975007 seen entering Reading station circa July 1987. Stuart Mackay Collection.

DMU

Date: 12th August 1987

The Ultrasonic Test Train 975008 + 975007 is seen at Penzance on 12.08.1987. Andy Cole.

DMU

Date: 1988

The Ultrasonic Test Train 975008 / 975007 in the sidings next to Leicester Station circa summer 1988. Brian Ward.

DMU

Date: 1988

The Ultrasonic Test Train 975008 / 975007 in the sidings next to Leicester Station circa summer 1988. Brian Ward.

DMU

Date: 1988

The Ultrasonic Test Train 975007 / 975008 in the sidings next to Leicester Station circa summer 1988. Brian Ward.
