Class 100 Gloucester RC&W 2-car DMUs
Diagrams
DMBS: BR 536 and DTC: BR 537
Alternate versions, same drawings but text in different positions:
Design Codes
These replaced Diagrams in 1980. DMBS: DQ 201 and DTC: DS 203
Works Pictures - British Railways
Photographed as part of the Derby Works collection, all taken on 17th June 1957.
Negative 57/724
Sc56095 and Sc50340
Negative 57/725
Sc56095 cab front
Negative 57/726
The gangway between Sc50340 (left) and Sc56095
Negative 57/727
Drivers compartment of Sc56095
Negative 57/728
A driver at the controls of either Sc50340 or Sc56095
Negative 57/729
The guard's area in the van of Sc50340
Negative 57/730
The van area in DMBS Sc50340 looking to the rear and through to the adjacent DTCL
Negative 57/731
The van area in DMBS Sc50340 looking forward to the passenger saloon through the sliding door
Negative 57/732
First class saloon in Sc56095
Negative 57/733
The interior of DMBS Sc50340, taken from the rear vestibule looking towards the cab
Negative 57/734
The interior of DMBS Sc50340, taken from the front of the vehicle looking towards the van
Negative 57/735
Interior of Sc56095, taken from the front vestibule looking towards the rear.
Negative 57/736
Interior of Sc50340, taken from the front vestibule looking towards the rear.
